CoreLine Panel gen6

Philips CoreLine panel: easy installation, excellent illumination

Popular downloads

View all downloads

Products

Product				Compare
CoreLine Panel gen6, 26 W, 1200x30 mm, VPC, 3600 lm, 4000 K, Wireless, Interact Ready RC132V G6 36S/840 WIA W30L120 OC 75006799 CoreLine Panel gen6, 1200x30 mm, Visible profile ceiling version, Steel, White, Signal white (RAL9003), Wireless driver Interact System-ready, 3600 lm, 26 W, 138 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, Beam angle 90°, Diamond, Polystyrene, IP20/44 \| Finger-protected; wire-protected, splash-proof, IK02 \| 0.2 J standard, Safety class II, Push-in connector 2-pole, SC \| Safety cable	138	3600	4000	Product leaflet PDF IES files IES Configure product
CoreLine Panel gen6, UltraEfficient, 22.5 W, 600x600 mm, VPC, 3600 lm, 4000 K, UGR19 RC132V G6 36S/UE840 PSU W60L60 OC 74982599 CoreLine Panel gen6, 600x600 mm, Visible profile ceiling version, Steel, White, Signal white (RAL9003), Power supply unit external (On/Off), 3600 lm, 22.5 W, 160 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, UGR19, Beam angle 90°, Diamond, Polystyrene, IP20/44 \| Finger-protected; wire-protected, splash-proof, IK02 \| 0.2 J standard, Safety class II, Push-in connector 2-pole, SC \| Safety cable	160	3600	4000	Product leaflet PDF IES files IES Configure product
CoreLine Panel gen6, 32 W, 600x600 mm, VPC, 4300 lm, 4000 K, Wireless, Interact Ready, IA4 RC132V G6 43S/840 SIA W60L60 OC IA4 58859200 CoreLine Panel gen6, 600x600 mm, Visible profile ceiling version, Aluminium, White, Signal white (RAL9003), Single layer powder coating, Ceiling, Sensor-ready driver Interact System-ready, Interact SNS210 sensor, 4300 lm, 32 W, 132 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, Beam angle 90°, White reflector, Diamond, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class II, Cable 0.3 m with connector 2-pole, 2 push-in connectors 2-pole, SC \| Safety cable	132	4300	4000	Product leaflet PDF IES files IES Configure product
CoreLine Panel gen6, 31 W, 600x600 mm, VPC, 4300 lm, 4000 K, Wireless, Interact Ready RC132V G6 43S/840 WIA W60L60 OC 75002999 CoreLine Panel gen6, 600x600 mm, Visible profile ceiling version, Steel, White, Signal white (RAL9003), Wireless driver Interact System-ready, 4300 lm, 31 W, 139 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, Beam angle 90°, Diamond, Polystyrene, IP20/44 \| Finger-protected; wire-protected, splash-proof, IK02 \| 0.2 J standard, Safety class II, Push-in connector 2-pole, SC \| Safety cable	139	4300	4000	Product leaflet PDF IES files IES Configure product
CoreLine Panel gen6, 26 W, 600x600 mm, VPC, 3600 lm, 4000 K, DALI RC132V G6 36S/840 PSD W60L60 OC 73515699 CoreLine Panel gen6, 600x600 mm, Visible profile ceiling version, Steel, White, Signal white (RAL9003), Power supply unit with DALI interface, 3600 lm, 26 W, 138 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, Beam angle 90°, Diamond, Polystyrene, IP20/44 \| Finger-protected; wire-protected, splash-proof, IK02 \| 0.2 J standard, Safety class II, Push-in connector 4-pole, SC \| Safety cable	138	3600	4000	Product leaflet PDF IES files IES Configure product
CoreLine Panel gen6, All-in, 31 W, 22 W, 600x600 mm, VPC, 3100 lm, 3600 lm, 4300 lm, 4000 K, UGR19 RC132V G6 31_36_43S/840 PSU W60L60OCUKI 75509399 CoreLine Panel gen6, 600x600 mm, Visible profile ceiling version, Steel, White, Signal white (RAL9003), Power supply unit external (On/Off), All-in, Multi Lumen, 3100 lm, 3600 lm, 4300 lm, 31 W, 22 W, 141 lm/W, 139 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, UGR19, Beam angle 90°, Diamond, Polystyrene, IP20/40 \| Finger-protected;Wire-protected, IK02 \| 0.2 J standard, Safety class II, Push-in connector 2-pole, SC \| Safety cable	141 139	3100 3600 4300	4000	Product leaflet PDF IES files IES Configure product
CoreLine Panel gen6, 45 W, 600x600 mm, VPC, 4800 lm, 4000 K, CRI>90, UGR19 RC132V G6 48S/940 PSU W60L60 OC IP65 73561399 CoreLine Panel gen6, 600x600 mm, Visible profile ceiling version, Steel, White, Signal white (RAL9003), Power supply unit external (On/Off), 4800 lm, 45 W, 107 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, CRI>90, UGR19, Beam angle 90°, Microprismatic lens, Polystyrene, IP65 \| Dust penetration-protected, jet-proof, IK03 \| 0.3 J, Safety class II, 2 cables 0.15 m with connectors 2-pole, Push-in connector 2-pole, SC \| Safety cable	107	4800	4000	Product leaflet PDF IES files IES Configure product
CoreLine Panel gen6, UltraEfficient, 23.5 W, 600x600 mm, VPC, 3600 lm, 4000 K, DALI, UGR19 RC132V G6 36S/UE840 PSD W60L60 OC 74983299 CoreLine Panel gen6, 600x600 mm, Visible profile ceiling version, Steel, White, Signal white (RAL9003), Power supply unit with DALI interface, 3600 lm, 23.5 W, 153 lm/W, 4000 K, (0.38, 0.38) SDCM ≤3, UGR19, Beam angle 90°, Diamond, Polystyrene, IP20/44 \| Finger-protected; wire-protected, splash-proof, IK02 \| 0.2 J standard, Safety class II, Push-in connector 4-pole, SC \| Safety cable	153	3600	4000	Product leaflet PDF IES files IES Configure product

13 items

of 2

Products per page

Description

Philips CoreLine panel Gen6 delivers on the CoreLine promise of innovation, easy installation, and excellent illumination. Designed as a direct replacement for functional luminaires in general lighting applications, this LED panel light's innovative All-in feature offers a choice of three lumen packages and three-color temperatures in a single luminaire. This makes it easy to select the right product, gives you the flexibility respond to customer preferences on site, and means fewer product codes on stock. Installing the CoreLine RC132V LED panel is quick and easy, using the product's quick connector or flywire. The CoreLine range includes Interact Ready luminaires with integrated wireless communications, ready to be used with Interact gateways, sensors, and software.
